Mini USB Connector on

Basic Info.

Model NO.	MUBX-5BMX-XXM0-01
Termination Interface: Style	Through Hole
Packaging Type	Tray/ Reel
Material - Plating Mating	Gold
Mini USB	5 Circuits (Loaded)
Transport Package	Export Cartons
Specification	ROHS
Trademark	ZYCON
Origin	Dongtai
HS Code	85369011
Production Capacity	1000000000

Product Description

SPECIFICATIONS
Current Rating:	1A for Pin
Dielectric Withstanding Voltage:	AC100V R.M.S.
Insulation Resistance:	100MΩ Min at DC500V
Contact Resistance(Low Level):	40MΩ Max.
Operation Temperature:	-55°C~+85°C

MATERIALS
Housing:	Thermoplastics,UL 94V-0 Rated
Contact:	Copper Alloy
Outer Shell:	Stainless Stell.
Inner Shell:	Stainless Stell.
Mid Shield Plate:	Stainless Stell.
EMC PAD:	Stainless Stell.

This type can solder as a wire as well as dip type
Micro usb now are mainly adopted by mobile,charging devices ,I/O port. Small size are more
popular,save space for consumer product and wins market share.
MATERIALSHousing: High Temperature Thermoplastic, Black Color, UL94V-0Contact: Copper Alloy with 30u" Gold platingShell: Copper Alloy
ELECTRICAL PERFORMANCESLow Level Contact Resistance: 50mΩ max.Insulation Resistance: 100MΩ min.Voltage Rating: 30Vrms max.Current Rating: 1A per contactDielectric Withstand Voltage: 100 VAC
ENVIRONMENTALOperating Temperature: -25~85°CMECHANICAL PERFORMANCEInsertion Force: 35N max.Unmating Force: 7N min.Durability: 5,000 insertion/ extraction cycles
SPECIFICATIONSProduct Specification: GS-12-174Packaging Specification: GS-14-873
PACKAGINGTrayTape/ Reel TARGET MARKET / APPLICATION Computers, laptops, serversPrinters, external drive units, monitorsDigital cameras, TV's, set-top boxModems, keyboards, instrumentationPoint-of-sale equipmentDataServersExternal Storage SystemsSupercomputers Features and Benefits
Metal shielding on all sidesSuperior shielding against RFI and EMIGrounding fingersGround mating halvesBeveled metal pinsProvides ground to PCB and strong board retentionDetention lockSecuring mating retention5,000 mating cyclesRugged durability
